CALCULATORS







There are probably dozens of sites with useful calculators but I felt that it took a long time to search for them when you needed them,often only to find a broken link so I have tried to collect the more commonly used formula calculators and tables here as a central reference point, there are links to the less common ones. Credit/link is given where known to original site.
Thanks to all those who have contributed.


No responsibility  can be taken for any errors or omissions or ensuing equipment damage or warranty infringements.
Copyright remains with the original source url which is shown wherever possible. Anyway it wasn't me I'm not clever enough.

RF Power Table (for 50 ohms)
CONVERSION CHART

dBm

Volts

Watts
60 dBm
223.61 V
1.00 kW
59 dBm
199.29 V
794.33 W
58 dBm
177.62 V
630.96 W
57 dBm
158.30 V
501.19 W
56 dBm
141.09 V
398.11 W
55 dBm
125.74 V
316.23 W
54 dBm
112.07 V
251.19 W
53 dBm
99.88 V
199.53 W
52 dBm
89.02 V
158.49 W
51 dBm
79.34 V
125.89 W
50 dBm
70.71 V
100.00 W
49 dBm
63.02 V
79.43 W
48 dBm
56.17 V
63.10 W
47 dBm
50.06 V
50.12 W
46 dBm
44.62 V
39.81 W
45 dBm
39.76 V
31.62 W
44 dBm
35.44 V
25.12 W
43 dBm
31.59 V
19.95 W
42 dBm
28.15 V
15.85 W
41 dBm
25.09 V
12.59 W
40 dBm
22.36 V
10.00 W
39 dBm
19.93 V
7.94 W
38 dBm
17.76 V
6.31 W
37 dBm
15.83 V
5.01 W
36 dBm
14.11 V
3.98 W
35 dBm
12.57 V
3.16 W
34 dBm
11.21 V
2.51 W
33 dBm
9.99 V
2.00 W
32 dBm
8.90 V
1.58 W
31 dBm
7.93 V
1.26 W
30 dBm
7.07 V
1.00 W
29 dBm
6.30 V
794.33 mW
28 dBm
5.62 V
630.96 mW
27 dBm
5.01 V
501.19 mW
26 dBm
4.46 V
398.11 mW
25 dBm
3.98 V
316.23 mW
24 dBm
3.54 V
251.19 mW
23 dBm
3.16 V
199.53 mW
22 dBm
2.82 V
158.49 mW
21 dBm
2.51 V
125.89 mW
20 dBm
2.24 V
100.00 mW
19 dBm
1.99 V
79.43 mW
18 dBm
1.78 V
63.10 mW
17 dBm
1.58 V
50.12 mW
16 dBm
1.41 V
39.81 mW
15 dBm
1.26 V
31.62 mW
14 dBm
1.12 V
25.12 mW
13 dBm
1.00 V
19.95 mW
12 dBm
890.19 mV
15.85 mW
11 dBm
793.39 mV
12.59 mW
10 dBm
707.11 mV
10.00 mW
9 dBm
630.21 mV
7.94 mW
8 dBm
561.67 mV
6.31 mW
7 dBm
500.59 mV
5.01 mW
6 dBm
446.15 mV
3.98 mW
5 dBm
397.64 mV
3.16 mW
4 dBm
354.39 mV
2.51 mW
3 dBm
315.85 mV
2.00 mW
2 dBm
281.50 mV
1.58 mW
1 dBm
250.89 mV
1.26 mW
0 dBm
223.61 mV
1.00 mW

dBm

Volts

Watts


0 dBm
223.61 mV
1.00 mW
-1 dBm
199.29 mV
794.33 uW
-2 dBm
177.62 mV
630.96 uW
-3 dBm
158.30 mV
501.19 uW
-4 dBm
141.09 mV
398.11 uW
-5 dBm
125.74 mV
316.23 uW
-6 dBm
112.07 mV
251.19 uW
-7 dBm
99.88 mV
199.53 uW
-8 dBm
89.02 mV
158.49 uW
-9 dBm
79.34 mV
125.89 uW
-10 dBm
70.71 mV
100.00 uW
-11 dBm
63.02 mV
79.43 uW
-12 dBm
56.17 mV
63.10 uW
-13 dBm
50.06 mV
50.12 uW
-14 dBm
44.62 mV
39.81 uW
-15 dBm
39.76 mV
31.62 uW
-16 dBm
35.44 mV
25.12 uW
-17 dBm
31.59 mV
19.95 uW
-18 dBm
28.15 mV
15.85 uW
-19 dBm
25.09 mV
12.59 uW
-20 dBm
22.36 mV
10.00 uW
-21 dBm
19.93 mV
7.94 uW
-22 dBm
17.76 mV
6.31 uW
-23 dBm
15.83 mV
5.01 uW
-24 dBm
14.11 mV
3.98 uW
-25 dBm
12.57 mV
3.16 uW
-26 dBm
11.21 mV
2.51 uW
-27 dBm
9.99 mV
2.00 uW
-28 dBm
8.90 mV
1.58 uW
-29 dBm
7.93 mV
1.26 uW
-30 dBm
7.07 mV
1.00 uW
-31 dBm
6.30 mV
794.33 nW
-32 dBm
5.62 mV
630.96 nW
-33 dBm
5.01 mV
501.19 nW
-34 dBm
4.46 mV
398.11 nW
-35 dBm
3.98 mV
316.23 nW
-36 dBm
3.54 mV
251.19 nW
-37 dBm
3.16 mV
199.53 nW
-38 dBm
2.82 mV
158.49 nW
-39 dBm
2.51 mV
125.89 nW
-40 dBm
2.24 mV
100.00 nW
-41 dBm
1.99 mV
79.43 nW
-42 dBm
1.78 mV
63.10 nW
-43 dBm
1.58 mV
50.12 nW
-44 dBm
1.41 mV
39.81 nW
-45 dBm
1.26 mV
31.62 nW
-46 dBm
1.12 mV
25.12 nW
-47 dBm
1.00 mV
19.95 nW
-48 dBm
890.19 uV
15.85 nW
-49 dBm
793.39 uV
12.59 nW
-50 dBm
707.11 uV
10.00 nW
-51 dBm
630.21 uV
7.94 nW
-52 dBm
561.67 uV
6.31 nW
-53 dBm
500.59 uV
5.01 nW
-54 dBm
446.15 uV
3.98 nW
-55 dBm
397.64 uV
3.16 nW
-56 dBm
354.39 uV
2.51 nW
-57 dBm
315.85 uV
2.00 nW
-58 dBm
281.50 uV
1.58 nW
-59 dBm
250.89 uV
1.26 nW
-60 dBm
223.61 uV
1.00 nW

This calculator can determine the resistance of up to 10 resistors in parallel.
Enter resistances into the boxes below and when all values have been input, click on the CALCULATE button and the result will appear in the box below that button.

 IMPORTANT: If you have new values to input, click the RESET button.
(Manually clearing the boxes does NOT reset stored values).











RESULT:

OHMS LAW FORMULAE from http://www.the12volt.com






RESISTOR COLOUR CODES
4,5 and 6 band
VK3UM Interdigital filter design calculator
THE 555 TIMER IC

MONOSTABLE TIMEOUT CALCULATOR
Type in the
Capacitor
Value

microFarads		 Type in the
Resistor
Value

Ohms		 This is
the
TIME OUT

SECONDS
Remember that the capacitor value is in microfarads.  A 10uF cap would be10, a 1nF cap would be 0.001, etc. Resistor values are in Ohms (ie: 1K is 1000, 1M is 1,000,000).



(Note: A 7555 is the CMOS version of the 555 and uses a fraction of the 555's power. Pinouts are the same.Use the LMC555 for lower volts supply)






ASTABLE SQUARE WAVE CALCULATOR
Type in the
Capacitor
Value

microFarads		 Type in the
Resistor1
Value

Ohms
Type in the
Resistor2
Value

Ohms
This is
the
TIME HIGH

SECONDS
This is
the
TIME LOW

SECONDS
This is
the
FREQUENCY

HERTZ
This is
the
DUTY CYCLE

Percentage

©Copyright 1999 * John Adams http://webhome.idirect.com/~jadams/electronics/555calcs.htm

An alternative calculator can be found here

DECIMAL TO BINARY CONVERTOR

Insert decimal number:

This free script provided by JavaScript Kit

METRIC CONVERTOR

IARU Locator calculator

Locator using Googlemaps




MATCHING BALUN CALCULATOR
by N9XCU

METRIC CONVERTOR

Length,weight,volume,temp
 www.englishforum.com

PI and T attenuator Calculator
design your own attenuators at

NGR/QRA CALCULATOR by G0HZK

PI Attenuator Calculator


http://www.random-science-tools.com/electronics/PI_attenuator.html





50 Ohm attenuators.
Here are some popular values using preferred values so approximate attenuation only.(R3=R1)
.

2.0dB : R1=390 R2= 12
2.5dB : R1=330 R2= 15
3.0dB : R1=390 R2= 18
3.5dB : R1=220 R2= 18
4.0dB : R1=220 R2= 22
5.0dB : R1=180 R2= 28
6.0dB : R1=150 R2= 39
10.dB : R1=100 R2= 68
12 dB : R1=100 R2= 82
14.dB : R1=68 ..R2=120
18 dB : R1=68 ..R2=180
20 dB : R1=56 ..R2=270

If you need more accurate values use the calculators.

ORDINANCE SURVEY Postcode to NG conversion BANDPASS FILTER CALCULATOR

Antenna Length Calculator     by K1WDU

Frequency MHz
= ft. = inches = cms



Useful rf calculators



Inductance,Capacitance,Reactance CALCULATORS
